Welcome to the Paper Converting Page!
PAPER CAPABILITIES
Download a PDF of Paper Converting Capabilities below.
SHEETER OVERVIEW
Sheeter #1
Max Roll Width: 57"
Min Roll Width: 16"
Max Cuts Across: 4"
Max Sheet Width: 56.5"
Min Sheet Width: 8"
Core Sizes: 3, 5, 6
Max O.D: 60
Min O.D: 20
Min Trim Req: 1/2"
Max Trim Per Slide: 1 1/2"
Min Basis Weight: 30# Uncoated 60# Coated
Max Basis Weight: 18pt
# of Backstands: 4
Sizes and square tolerance: +/- 0.03"
Sheeter #2
Max Roll Width: 65"
Min Roll Width: 18"
Max Cuts Across: 4"
Max Sheet Width: 64.5"
Min Sheet Width: 9"
Core Sizes: 3-12
Max O.D: 72
Min O.D: 20
Min Trim Req: 1/2"
Max Trim Per Slide: 2 1/2"
Min Basis Weight: 30# Uncoated 50# Coated
Max Basis Weight: 60pt
# of Backstands: 6
Sizes and square tolerance: +/- 0.03"
SLITTING & REWINDING OVERVIE
Lil Cam
Lil Cam
Lil Cam
Max Roll Width On: 72"
Max Roll Width Off: 72"
Min Slit Width: 6"
Max Diameter On: 50"
Max Diameter Off: 50"
Core Sizes On: 3",5",6"
Core Sizes Off: 3",5",6"
Min Trim Required: 1/2"
Min Basis Weight: 24#
Max Basis Weight: 16pt.
Number of Slitters: 8
Size Tolerance: +/-.0625
Ellie
Lil Cam
Lil Cam
Max Roll Width On: 90"
Max Roll Width Off: 87"
Min Slit Width: 6"
Max Diameter On: 60"
Max Diameter Off: 60"
Core Sizes On: 3",4",5",6",8",12"
Core Sizes Off: 3",5",6",8",12"
Min Trim Required: 1/2"
Min Basis Weight: 24#
Max Basis Weight: 30pt.
Number of Slitters: 6
Size Tolerance: +/-.0625
Big Cam
Lil Cam
Big Cam
Max Roll Width On: 122"
Max Roll Width Off: 122"
Min Slit Width: 6"
Max Diameter On: 84"
Max Diameter Off: 60"
Core Sizes On: 3",5",6",8",12"
Core Sizes Off: 3",5",6",8",12"
Min Trim Required: 1/2"
Min Basis Weight: 15#
Max Basis Weight: 30pt.
Number of Slitters: 5
Size Tolerance: +/-.0625
GUILLOTINE TRIMMER OVERVIEW
Guillotine #1
Max Cutting Width: 54"
Min Cutting Width: 54"
Minimum Cut: 4"
INTERESTED IN A CUSTOM JOB?
